MC88CH1O1CRT1L
Safety magnetic sensor with LED, Rectangular plastic housing, 0,1m PVC with M12 connector, Right Exit, 1NO+1NC output reed contacts, Max switching voltage 12/24 Vac/dc, Max switching current 250mA, Max switching power 6W, Operating temp. -25...+80 C, IP67Specifications
Switch ON distance
18 mm
Switch OFF distance
30 mm
Output type
Reed switch
Max switching current
250 mA
Connection type
Cable with connector
Housing type
Rectangular
Degree of protection
IP67
Downloads
Data sheet
Manuals
Images
Drawings
Brochures
Videos
Certifications
3D dynamic generator
Related accessories
MC88CM1
Safety magnetic actuator, Rectangular plastic housing, Sao 5mm, Sar 15mm, Operating temp. -25...+80 C, IP69K
MC88CM2
Safety magnetic actuator, Rectangular plastic housing, Sao 8mm, Sar 18mm, Operating temp. -25...+80 C, IP69K
MC88CM3
Safety magnetic actuator, Rectangular plastic housing, Sao 18mm, Sar 30mm, Operating temp. -25...+80 C, IP69K
CON14NFA2
Connection cable, Angled M12 plug, Female, 4-wires, PVC 2m cable, IP67, Temperature -25 - +80C
CON14NFA5
Connection cable, Angled M12 plug, Female, 4-wires, PVC 5m cable, IP67, Temperature -25 - +80C
CON14NFS2
Connection cable, Straight M12 plug, Female, 4-wires, PVC 2m cable, IP67, Temperature -25 - +80C
CON14NFS5
Connection cable, Straight M12 plug, Female, 4-wires, PVC 5m cable, IP67, Temperature -25 - +80C
