Sensors
The Carlo Gavazzi Group
PB3PPPA-1
Polarized Retro-reflective Photoelectric Sensor, Range 3000mm, red polarized modulated light 660nm, Power Supply 10-40VDC, PNP Output, NO and NC, Light and Dark Switching, M12 PlugSpecifications
Output type
PNP
Output function
Complementary (NO+NC)
Connection Type
Connector M12
Housing style
Cylindrical, threaded barrel
Housing Material
Plastic
Type of light
Polarized red light
Sensing mode
Light-/dark switching
Degree of protection
IP67
Rated Operetional voltage UB at DC
10 V ... 40 V
Downloads
Data sheet
Manuals
Images
Drawings
Certifications
Related accessories
APB-1
Mounting Bracket for PB-Series, Size 117.5 x 22 x 37 mm, Steel, black
CON14NFA2
Connection cable, Angled M12 plug, Female, 4-wires, PVC 2m cable, IP67, Temperature -25 - +80C
CON14NFA5
Connection cable, Angled M12 plug, Female, 4-wires, PVC 5m cable, IP67, Temperature -25 - +80C
CON14NFS2
Connection cable, Straight M12 plug, Female, 4-wires, PVC 2m cable, IP67, Temperature -25 - +80C
CON14NFS5
Connection cable, Straight M12 plug, Female, 4-wires, PVC 5m cable, IP67, Temperature -25 - +80C
ERT25
Reflective tape suitable for polarized light, Reduction factors on distance 0.23, 25 mm wide x 45.7 meters long (1 roll)
ERT50
Reflective tape suitable for polarized light, Reduction factors on distance 0.34, 50 mm wide x 45.7 meters long (1 roll)
ER1
High quality reflectors for retro-reflective photoelectric switches, Reduction Factors on Distance 0.20 , 51.0 x 17.5 x 6.0 housing, IP67 IP69K
ER100
High quality reflectors for retro-reflective photoelectric switches, Reduction Factors on Distance 1.20 , 100.0x100.0x92.0 housing, IP67 IP69K
ER390
High quality reflectors for retro-reflective photoelectric switches, Reduction Factors on Distance 0.39 , 23.0x47.0x9.0 housing, IP67 IP69K
ER4
High quality reflectors for retro-reflective photoelectric switches, Reduction Factors on Distance 1.00 , 84.00mm diameter x 7.4 mm housing, IP67 IP69K
ER4060
High quality reflectors for retro-reflective photoelectric switches, Reduction Factors on Distance 0.81, 40.0x60.0x8.0mm housing, IP67 IP69K
ER420
High quality reflectors for retro-reflective photoelectric switches, Reduction Factors on Distance 0.54 , 42.00mm diameter x 6.00 mm housing, IP67 IP69K
ER42182
High quality reflectors for retro-reflective photoelectric switches, Reduction Factors on Distance 0.65, 182.0x42.0x8.0mm housing, IP67 IP69K
ER423
High quality reflectors for retro-reflective photoelectric switches, Reduction Factors on Distance 0.54 , 42.00mm diameter x 6.8mm housing, IP67 IP69K
